  #1
Old 08-03-2011, 12:19 AM
Member
2004 Ford F-150

Join Date: Aug 2011
Location: Los Angeles
Vehicle: 2004 Ford F150
Posts: 13
Lightbulb Light Bar and Switch Panel Install

So I just finished installing a Randy Ellis Designs light bar and two pair of Hellas (500ff and 700ff driving lights) on my 2004 FX4 screw. I fabbed up a custom switch panel in the cubby beneath the pull out cupholder in the dash and installed some aircraft style safety toggles. Here are the build photos and some brief captions:

Here is the "Pre" photo. As you can see, the previous owner installed two PIAA fogs in the gap in the bumper.
Click the image to open in full size.

I chose the Randy Ellis Designs light bar because I liked the 1-3/4" tubing and it also happened to mount in between the existing PIAA fogs without alteration.
Click the image to open in full size.

Click the image to open in full size.

Painted the hardware for the Hellas.
Click the image to open in full size.

Lights mounted.
Click the image to open in full size.

Click the image to open in full size.

The wiring under the hood is pretty basic so I will skip that. I mounted the relays near the firewall on the passenger side in case you are wondering. So, now, here is the switch panel which I am quite proud of. I started by removing the empty (and useless might I add) cubby beneath the pull out cupholder. I slotted the top of it with a dremel to make room for a piece of 1/8" ABS textured plastic which would make the front of my switch panel. I also cut a large portion out of the top in order to install the switches from the back.
Click the image to open in full size.

Click the image to open in full size.

Next I cut out the ABS face plate using a paper template and slid it in through the top, trimming to fit.
Click the image to open in full size.

Click the image to open in full size.

Next, I drilled the holes for the switches, and test fitted the switches. When I was comfortable with the fit, I made some gussets and used a plastic epoxy to tie everything together.
Click the image to open in full size.

Click the image to open in full size.

Click the image to open in full size.

Finally, I wired the relay leads to the switches and then from the switch to an empty port on the fuse box which only operates when the ignition is on (no dead battery if the lights are left on without the key in). I tied the existing PIAA fogs into the switch panel as well. So, three of the switches are used: PIAA 510 fogs, Hella 500ff's, and Hella 700ff's (one dummy switch for future use just because I felt like it). I am super happy with it, it looks pretty professional and is not too obnoxious like some of the bright LED switches out there.
Click the image to open in full size.

Click the image to open in full size.

Click the image to open in full size.

Click the image to open in full size.

You all know how hard it is to do lights justice in a picture but here it is anyway...
Click the image to open in full size.
Reply With Quote
  #2
Old 08-03-2011, 04:50 PM
Senior Member
2006 Ford F-150

Join Date: Dec 2008
Location: Goddard, KS
Vehicle: 2006 Ford F150
Posts: 879
Tanner Crusinbery
That is nice bro!!
I switches looks VERY clean. I wish I had one of those cubby's.
How do you like the 700ff's?
With all those lights on the front, should seem like daylight!!
Reply With Quote
  #3
Old 08-03-2011, 06:21 PM
Technical Article Contributor
1998 Ford F-150

Join Date: Jan 2007
Location: Live Oak, FL
Vehicle: 1998 Ford F-150
Posts: 10,365
Raptor05121 Raptor05121
Send a message via AIM to Raptor05121 Send a message via MSN to Raptor05121 Send a message via Yahoo to Raptor05121
You'll hardly see those kind of switches in any small aircraft. More like military safety switches for missiles or something. You did great with that install! Looks very clean and looks like you have a lot of light. Any pics of the wiring?
__________________
-Alex


4.2L V6 - M5OD ~350K miles | SCT XCal3 | K&N Series-77 | 16" Dual Efans | Magnaflow High-Flows
50W 5000K FX-R Projectors | Philips LumiLED Taillights | 60" Plasmaglow Fire & Ice | 2" Drop Shackles
Reply With Quote
  #4
Old 08-04-2011, 03:47 PM
Technical Article Contributor
2005 Ford F-150

Join Date: May 2007
Location: St. Louis, MO
Vehicle: 2005 Ford F150
Posts: 1,219
Nice work, I used the same place for my switches when I did my light bar last year. I just used industrial grade toggle switches.

Click the image to open in full size.
__________________
Reply With Quote
  #5
Old 08-04-2011, 03:54 PM
Senior Member
2006 Ford F-150

Join Date: Feb 2011
Location: Grapevine, TX
Vehicle: 2006 Ford F150
Posts: 883
haha I love your switches. freakin sweet. It looks like they are more for oil slick, missiles and smoke screen lol
__________________

14"Magnapack, Y-pipe, 2 4x18 45'd tips
http://www.youtube.com/watch?v=K2Zfpd66360&hd=1
6" skyjacker lift, 1" daystar spacer, 35x12.5 nitto trails and 17x9 black rhino sidewinders
Gotts mod, Platinum Burners series motorcycle headlights under the rear bumper.
Reply With Quote
  #6
Old 08-04-2011, 03:58 PM
Senior Member
Garage is empty, add now

Join Date: Apr 2010
Location: Hillsboro, OR
Vehicle: 2004 Ford F150
Posts: 449
Looks good. I had a bunch of lights like that on my ranger (actually 10 after market forward facing lights) and had a switch for them. I got really tired of reaching down to turn off the brights when i a car came around the corner. With my F150 I just wired them to my stock brights with a relay so they come on with the stock brights. So much simpler and I find that I use them more often because of the convenience factor. Your install looks very good though.
__________________
2004 Lariat Screw. Leveled, 33" Toyo M/Ts on 20s, Pioneer F700BT, 110V outlet, OBA, rear air bags & semi horns, Gott's, Hella driving lights behind grill. Dual Dayton OH 10s getting 1000W in a ported box paired with amped Pioneer TS-D6802Rs.
The old: 2004 Ranger FX4, 4" SL W/ Fox C/Os, 3" BL, 35s, 4.88s, Home made bumpers & headache rack etc.
The toy: 2012 Yamaha WR450F
Reply With Quote
  #7
Old 08-04-2011, 04:57 PM
Senior Member
2004 Ford F-150

Join Date: Dec 2010
Location: Harlem, GA
Vehicle: 2004 Ford F150
Posts: 822
So Complicating
That install is nice and clean. Got any pics of the output of all those lights?
__________________
http://i1108.photobucket.com/albums/h412/atr04screw/08965808-62db-4151-9b44-0199190af800_zps1b152076.jpg
2004 Supercrew Lariat 4x4
5.4L
20" Pro Comps with 275/65/20 Trail Grapplers
Aries Brush Guard with PIAA 540s
Reply With Quote
  #8
Old 08-04-2011, 05:44 PM
Member
Garage is empty, add now

Join Date: Apr 2010
Location: Wisconsin
Vehicle: 2007 Ford F150
Posts: 40
how are the piaa lights mounted in the gap in the bumper?
Reply With Quote
  #9
Old 08-04-2011, 05:52 PM
Member
2005 Ford F-150

Join Date: May 2011
Location: NC
Vehicle: 2005 Ford F150
Posts: 64
Very nice looking lights and switch panel!! If I ever need or want to add more switches, I will definitely put them in the cubby like that!
__________________

2005 Silver 4x2 Supercab XLT 5.4
285/70/17 Cooper Discoverer AT3, 2" Autospring Level
20% Tint on Front Windows
55 Watt Driving Lights in Lower Grille
100 Watt Long Range Lights Behind Grille
Cobra 29LX CB with 4' Wilson Antennas
Reply With Quote
  #10
Old 08-04-2011, 10:23 PM
Member
2004 Ford F-150

Join Date: Aug 2011
Location: Los Angeles
Vehicle: 2004 Ford F150
Posts: 13
Poolboy......the output of the 700ff's is about the same as the 500ff's but I really like the way the different sizes look on the bar.

Raptor....Don't have any great pics of the wiring right now, I will try to take some this weekend. It is all pretty tucked away but I'll see what I can do.

Watson....looks like we have similar tastes. Props on the light bar, I wish I had the tools to fab stuff like that on my own.

atr04screw.......haven't had a chance to get the truck out of the city yet and check out the light output. I'll take some pics when I do.

Dave0....the PIAA's on the bumper are mounted right to the bumper in that gap. Drilling was required. (previous owner did those...and did a good job)
Reply With Quote
  #11
Old 08-05-2011, 09:59 AM
Member
Garage is empty, add now

Join Date: Apr 2010
Location: Wisconsin
Vehicle: 2007 Ford F150
Posts: 40
any chance you have pics of the mounting job he did? i have an extra set of piaa lights from my ranger that id like to mount in a location like that.
Reply With Quote
  #12
Old 08-06-2011, 03:55 PM
Senior Member
2006 Ford F-150

Join Date: Feb 2011
Location: Grapevine, TX
Vehicle: 2006 Ford F150
Posts: 883
wherd you get the switch panel and those safety covers
__________________

14"Magnapack, Y-pipe, 2 4x18 45'd tips
http://www.youtube.com/watch?v=K2Zfpd66360&hd=1
6" skyjacker lift, 1" daystar spacer, 35x12.5 nitto trails and 17x9 black rhino sidewinders
Gotts mod, Platinum Burners series motorcycle headlights under the rear bumper.
Reply With Quote
  #13
Old 08-06-2011, 08:59 PM
Member
2004 Ford F-150

Join Date: Aug 2011
Location: Los Angeles
Vehicle: 2004 Ford F150
Posts: 13
Quote:
Originally Posted by hardrock3742 View Post
wherd you get the switch panel and those safety covers
Got the 1/8" ABS textured plastic on Amazon for like $15. Safety Toggles at pep boys for $8 each. Switch panel took me about 8 hours all said and done, getting it to fit just perfect in that cubby takes time.
Reply With Quote
  #14
Old 08-06-2011, 09:14 PM
Member
2004 Ford F-150

Join Date: Aug 2011
Location: Los Angeles
Vehicle: 2004 Ford F150
Posts: 13
Here are some wiring pics:

Here is where I tied into the fuse box...
Click the image to open in full size.

Here is where the switch wires from the fuse box and firewall enter the dash to the switch panel. You can also see where they run behin the dash to get across to the fuse box on the passenger side.
Click the image to open in full size.

The inline fuses for the switches tucked up under the dash but still accessible....
Click the image to open in full size.

Here is where the wires come through the fire wall on the driver's side and then head up into existing wire tunnel just below the windshield...
Click the image to open in full size.

Wires come out of the wire tunnel behind the battery. One of the relays is also tucked in behind the battery, too hidden for a good picture...
Click the image to open in full size.

Other relay mounted to firewall ground...
Click the image to open in full size.

Connecting the lights to the positive battery terminal. You can also see the PIAA fog relay tucked away to the left if you look close (previous owner install)...
Click the image to open in full size.

Here is the total view, pretty tucked away for the most part. I'll probably get some more plastic tubing for the red power leads, I don't like the way they catch your eye...
Click the image to open in full size.

Here is the wiring up front by the lights, the blue connectors are the grounds for each light, bolted to the frame. Then all the wires run off to the left toward the battery. I used rubber heat shrink wiring tubing up front for protection, although I didnt actually shrink it with a heat gun, didn't feel the need.

Click the image to open in full size.

ENJOY! I AM!

Last edited by O-FOUR FX4; 08-15-2011 at 10:06 PM.
Reply With Quote
  #15
Old 08-06-2011, 09:16 PM
Member
2004 Ford F-150

Join Date: Aug 2011
Location: Los Angeles
Vehicle: 2004 Ford F150
Posts: 13
Dave0,

here is a pic of the PIAA's on the bumper. Just a hole in the bumper.
Click the image to open in full size.
Reply With Quote
