  #1
Old 12-22-2011, 08:41 PM
Member
Garage is empty, add now

Join Date: Dec 2011
Posts: 54
trailer towing package?

How do you tell if a F150 is equipped with this option? Looking at buying a trailer plug harnesses and it asks with or without tow package.

Any feedback would be helpful.

Butch
Reply With Quote
  #2
Old 12-22-2011, 08:45 PM
Senior Member
Garage is empty, add now

Join Date: Jun 2007
Location: Utah
Vehicle: 1999 Ford F-150 5.4
Posts: 5,083
If you had it already you wouldn't need to buy a trailer plug probably unless your replacing your stock one. Mine has the trailer package. Includes reciever hitch trailer plug trans oil cooler and maybe more.
__________________

1999 F-150 xlt 5.4 4x4
1971 Mach 351c 5 speed TKO600 Tremac-sold!
Reply With Quote
  #3
Old 12-22-2011, 08:57 PM
Senior Member
1999 Ford F-150

Join Date: Oct 2010
Location: Northwest Mississippi
Vehicle: 2004 Ford F-150
Posts: 813
Kendall Harvey BOOMERSOCOM @urbanhostageoffroad
if you have a trans oil cooler blotted to the radiator one the passenger side than you have one. but there were to options i think a 4 pin and an 8 pin, im updating to an 8 pin set up after Christmas
__________________

2004 F-150 FX4
URBAN HOSTAGE OFF-ROAD
<---
6"x6" Decals In Stock Now!!!!!! <---
UHO facebook <---Like It Please! :)
Follow us on Instagram!! :) @Urbanhostageoffroad
1999 F-150 XLT - SOLD
Reply With Quote
  #4
Old 12-24-2011, 03:26 PM
Senior Member
Garage is empty, add now

Join Date: Jul 2004
Location: Easton, Pa.
Vehicle: 2002 F150 super crew
Posts: 4,981
Towing package from factory usually includes a trans cooler, 4 and 7 pin trailer connectors lighting and control, and hitch receiver and could include a larger alternator and battery.
A connector is included under the dash to plug in an electric brake controller using the correct adapter per the mfger of the controller.
Depending on states laws, electric brakes are often required with trailer weights over 2500.
Good luck.
For towing capability, your truck has a max rated 'gross combined weight' rateing as it came equipped from Ford.
If you intending to tow high weights, pay attention to this.
Good luck.
Reply With Quote
  #5
Old 12-24-2011, 10:02 PM
Member
Garage is empty, add now

Join Date: Dec 2011
Posts: 54
Well I found I do not have the tow package. The boat has surge brakes and I pulled it for the last few years with a 98 Dodge dakota 2x with a 3.9 6 banger. So a F150 (4.6 V8) with out tow package will handle this easy. Just added a class III reese hitch on the truck: now I just need to find the correct harness.
Reply With Quote
  #6
Old 12-24-2011, 10:09 PM
Senior Member
1999 Ford F-150

Join Date: Oct 2010
Location: Northwest Mississippi
Vehicle: 2004 Ford F-150
Posts: 813
Kendall Harvey BOOMERSOCOM @urbanhostageoffroad
Quote:
Originally Posted by bassin butch View Post
I just need to find the correct harness.
LMC has both 4 and 7 not expensive i dont think
Reply With Quote
  #7
Old 12-24-2011, 11:06 PM
Member
Garage is empty, add now

Join Date: Dec 2011
Posts: 54
Quote:
Originally Posted by BOOMER2011 View Post
LMC has both 4 and 7 not expensive i dont think
LMC? Got a link?

Thanks in advance
Butch
Reply With Quote
  #8
Old 12-25-2011, 04:46 AM
Senior Member
Garage is empty, add now

Join Date: Oct 2004
Location: Texas
Vehicle: 2002 Ford F150 FX4
Posts: 489
Quote:
Originally Posted by bassin butch View Post
LMC? Got a link?

Thanks in advance
Butch
http://www.lmctruck.com/icatalog/fe/full.aspx?Page=114
__________________
2001 F150 XLT 2WD 4.2 M5OD-Sold
2002 F150 FX4 5.4-Totaled
1997 F250LD XLT 2WD 4.6-Work Horse
1999 F150 XLT 4x4 4.6 M5OD-Daily Beater
Reply With Quote
  #9
Old 12-25-2011, 10:27 AM
Member
Garage is empty, add now

Join Date: Dec 2011
Posts: 54
Erik that was a big help. I really thank you!

Have a great day
Butch
Reply With Quote
  #10
Old 12-26-2011, 05:15 PM
Junior Member
Garage is empty, add now

Join Date: Dec 2011
Posts: 1
I need help figuring out if I have the towing pkg. or not. When I purchased Truck 2003 Ford F-150, 4.2, I was told it was included. I have a 4 pin plug, but a square hitch, it looks to be mounted on frame. I want to make sure, because purchasing travel trailer. Side sticker says I can haul 6,300 lbs. Also, do I need a larger transmission cooler or does this all come together. I have been reading some forums, now more confused. Please help!!!
Reply With Quote
  #11
Old 12-26-2011, 05:54 PM
Senior Member
1999 Ford F-150

Join Date: Oct 2010
Location: Northwest Mississippi
Vehicle: 2004 Ford F-150
Posts: 813
Kendall Harvey BOOMERSOCOM @urbanhostageoffroad
do you have a trans cooler stock? if you do then yes you have a tow package if not than you dont, its mounted below the radiator on the pass side
__________________

2004 F-150 FX4
URBAN HOSTAGE OFF-ROAD
<---
6"x6" Decals In Stock Now!!!!!! <---
UHO facebook <---Like It Please! :)
Follow us on Instagram!! :) @Urbanhostageoffroad
1999 F-150 XLT - SOLD
Reply With Quote
  #12
Old 12-27-2011, 02:30 AM
Senior Member
Garage is empty, add now

Join Date: Jul 2004
Location: Easton, Pa.
Vehicle: 2002 F150 super crew
Posts: 4,981
This question about towing capacity comes up very often and is never understood enough.
There are a number if items you need to know for selecting trailer weights.
1.What is the Gross Combined Weight Rateing of the truck.
That is the max combined weight of the truck and trailer in a 'loaded' condition.
For example: A truck's GCWR of 11,000 lbs with a truck weight of 6000 lbs loaded with passengers, gas and all other items leaves the loaded trailer weight of 5000 lbs.
2. Has the truck had tire size down grade that does not have the same weight rateing, are you equipped with a trailer brake controller and 7 pin tow connector?
There are many sub items that go into legal towing if one looks at all the items.
The GCWR tells it all no matter what you are told the truck can tow.
.
As a comment, towing a hard travel trailer with a 4.2 is not a real good idea unless it is super light or is a pop-up type.
Good luck.
Reply With Quote
  #13
Old 12-27-2011, 08:58 AM
glc glc is offline
Senior Member
Garage is empty, add now

Join Date: Dec 2006
Location: Joplin MO
Vehicle: 2003 Ford F150
Posts: 28,286
I haven't seen a 4.2 truck that's rated to tow 6300#. That's not a good combo for towing a travel trailer.
__________________
2003 F-150 XL RCSB 2wd 4.2 M5OD 3.55 LS
Reply With Quote
  #14
Old 12-27-2011, 09:12 AM
Senior Member
1999 Ford F-150

Join Date: Oct 2010
Location: Northwest Mississippi
Vehicle: 2004 Ford F-150
Posts: 813
Kendall Harvey BOOMERSOCOM @urbanhostageoffroad
here is the towing specs for our trucks:
http://www.fordf150.net/specs/99tow.php
__________________

2004 F-150 FX4
URBAN HOSTAGE OFF-ROAD
<---
6"x6" Decals In Stock Now!!!!!! <---
UHO facebook <---Like It Please! :)
Follow us on Instagram!! :) @Urbanhostageoffroad
1999 F-150 XLT - SOLD
Reply With Quote
  #15
Old 12-27-2011, 04:29 PM
glc glc is offline
Senior Member
Garage is empty, add now

Join Date: Dec 2006
Location: Joplin MO
Vehicle: 2003 Ford F150
Posts: 28,286
Those specs are generic - they do not consider the engine, transmission, and axle ratio. This is a lot more accurate and specific:

http://www.trailerlife.com/Towing-Guides/

To clcleary, here is a direct link to the 2003 guide:

http://www.trailerlife.com/assets/Do...?id=4294968263

Depending on all these factors, a 2003 with a 4.2 can tow between 2000# and 5700#. No matter what, 6300# is over ratings.
__________________
2003 F-150 XL RCSB 2wd 4.2 M5OD 3.55 LS
Reply With Quote
